Construction

Rotational Telehandlers

Pegasus – 400° 38.16

Max Capacity:

3,800 kg

Max Lift Height:

15.7 m

Total Weight:

13,100 kg

Max Power:

73.4 kW (98 hp)

Engine Brand:

Kubota
















      Dieci Pegasus Telehandler
      ABOUT

      Product Info

      The Pegasus 38.16 is a rotational telehandler with 400° non-continuous rotations. It is characterised by extreme flexibility of use and there are a wide range of attachments that allow a single vehicle to operate as a telehandler, aerial platform and crane.

      The main features of this model are ease of use, strength, and a full range of safety devices including a load limiter and cutting-edge equipment for total control of the vehicle in every effort, load, terrain and speed condition.

      The wide and comfortable cab is equipped with a colour TFT display thanks to an intuitive graphical interface, allowing the operator to keep all the vehicle functions under control.

      TECHNICAL

      Specifications

      Length: 6,740 mm

      Width: 2,380 mm

      Height: 3,035 mm

      Maximum capacity: 3,800 kg

      Maximum lifting height: 15.7 m

      Pull-out force: 5,700 daN

      Towing force: 7,300 daN

      Maximum speed: 25 km/h

      Unladen weight: 13,200 kg

      Brand: Kubtoa

      Fuelling: Diesel

      Cooling: Liquid

      Displacement: 3,769 cm³

      Nominal power: 73.4 kW (98 hp)

      RPM at nominal power: 2,600 rpm

      Emission standard: Stage IIIA/Tier 3

      Hydraulic pump capacity: 135 l/min

      Maximum operating pressure: 23 MPa

      Transmission type: Hydrostatic with variable flow pump

      Standard tyres: 400 / 70 x 20”
