Construction
Max Capacity:
Max Lift Height:
Total Weight:
Max Power:
Engine Brand:
The Zeus 35.10 is meticulously engineered to provide operators with an optimal blend of power and agility, especially when maneouvering heavy loads in tight spaces.
The Dieci range of Zeus telehandlers is crafted to accommodate a wide array of equipment necessary for various tasks on construction sites, including forks, loaders, lifting hooks, jibs with winches, grippers, material baskets, mixing buckets, concrete ladles, sweepers, salt spreaders, and snowplow blades.
Length: 4,950 mm
Width: 2,290 mm
Height: 2,310 mm
Maximum capacity: 3,500 kg
Maximum lifting height: 9.75 m
Pull-out force: 5,700 daN
Towing force: 7,300 daN
Maximum speed: 30 km/h
Unladen weight: 8,000 kg
Brand: FPT
Fuelling: Diesel
Cooling: Liquid
Displacement: 4,485 cm³
Nominal power: 93 kW (125 hp)
RPM at nominal power: 2,200 rpm
Emission standard: Stage IIIA/Tier 3
Hydraulic pump capacity: 130 l/min
Maximum operating pressure: 24 MPa
Transmission type: Hydrostatic with variable displacement pump
Standard tyres: 400 / 70 x 20″
